HSN600WP
HSN
1300 mm working width; 600 mm steel-pin beater; variable-speed feed drive
Fiber opening; material suitability subject to sample evaluation
The HSN600WP combines a 1300 mm working width with a 600 mm steel-pin opening beater. The listed configuration includes an inverter-controlled feed gearbox, a suction fan and a 30 kW main motor. Submit representative material for suitability review before selecting the machine.
Item | Reference specification |
|---|---|
Model | HSN600WP |
Working width | 1300 mm |
Opening beater diameter | 600 mm |
Beater type | Steel pins |
Feed roller diameter | 72 mm |
Feed gearbox motor | 2.2 kW with inverter control |
Suction fan power | 4.0 kW |
Main motor | 30 kW, six-pole; drive arrangement confirmed in the quotation |
Controls | Motor overload protection and frequency-converter control; starting method and component selection to be confirmed |
Reference production rate | 260-380 kg/h, subject to material and operating conditions |
Machine dimensions | 3020 x 2150 x 1490 mm |
Machine weight | 2550 kg |
Capacity is a reference value, not a guaranteed result for every material. Actual throughput and fiber condition depend on material composition, preparation, feeding and operating settings. Confirm motor starting method, inverter arrangement, electrical components, power supply and the final equipment scope in the formal quotation. Component brands are not fixed unless agreed.
Review item | Information to provide |
|---|---|
Input material | Material type, composition, preparation, feed dimensions and photos or representative samples |
Recovered-fiber target | Intended downstream application and required fiber condition |
Production requirement | Target output, working hours and upstream or downstream machinery |
Installation | Voltage, phase, frequency, floor space, access and dust-system connections |
Supply scope | Required feeding, conveying, controls, accessories and destination |
Evaluate samples and agree the trial objectives before ordering. Material suitability and recovered-fiber quality must be confirmed for the intended process. Prices, delivery schedules and other commercial terms are quoted for each project.
