HSN1060
HSN
84451190
High efficiency and Low power consumption
Textile Waste Recycling
The HSN1060 opens suitable fabric scraps and rags for mechanical fiber recovery. It is an option for reviewing textile and garment production offcuts where the recovered fiber will be assessed for a defined reuse application.
Start with the actual waste stream: fiber blend, knitted or woven construction, coatings, incoming piece size and contamination all affect opening performance. Confirm whether cutting, sorting or additional cleaning is needed as part of the complete process.
Potential recovered-fiber uses include mattress, bedding, quilt, pillow and sofa filling. Each end use requires a material trial and acceptance criteria. This machine alone does not guarantee spinning-grade fiber or a fixed recovery quality.
| Item | HSN1060 reference specification |
|---|---|
| Production rate | 120-160 kg/h |
| Opening roller diameter | 600 mm |
| Card clothing | 3.5 or 4.5 teeth/inch |
| Fan power | 1.5 kW |
| Main motor power | 18.5 kW |
| Overall dimensions (L x W x H) | 2600 x 1450 x 1550 mm |
| Net weight | 800 kg |
Reference values apply to HSN1060 only. Production rate depends on material preparation, feeding and operating settings. Confirm the motor arrangement, electrical supply, safety guards, accessories and installation dimensions in the final quotation and approved drawing.
Country and intended installation location
Waste photos, fiber composition and incoming scrap size
Required hourly output and intended recovered-fiber use
Site power supply, available floor space and existing line equipment
Representative samples help establish an appropriate trial procedure and evaluate the resulting fiber before an order is finalized. Price and commercial terms are quoted for the agreed project scope.
